Canon AD-E1 Multifunction Shoe Adapter


Stock levels may vary, if your order is urgent, please enquire about availability

Free Shipping for Orders over $98* (*excludes bulky items)
  • Adapts Shoe Accessories to Multi-Function Shoe
  • Locking Shoe Design
  • Maintains Weather Sealing

Canon AD-E1 Multifunction Shoe Adapter offers an easy and ergonomic way of attaching Shoe Accessories to Multi-Function Shoe. It has a dual-locking shoe design to adapt Speedlite accessories and provides a secure connection to most of today’s shoe type. This adapter also maintains a complete weather-sealed design.

Product Features in Detail


Connect, adapt, create
The AD-E1 is a Multi-function shoe adaptor that adapts conventional hotshoe Speedlites with a weather sealed foot to Multi-function shoe cameras, whilst maintaining dust and weather resistance.

Connect conventional Speedlites
Attach the Multi-Function Shoe Adapter AD-E1 to Speedlite flashes with a 5-pin weather sealed foot and use on the latest EOS R-series cameras with a Multi-function shoe, maintaining full control.

Use in all weathers
With the same weather resistance as the latest Speedlite flashes, the Multi-Function Shoe Adapter AD-E1 will protect the Multi-function shoe connection from water and dust ingress thanks to JIS 2 standard weather sealing.

Secure lockable connection
Attach the Multi-Function Shoe Adapter AD-E1 with confidence and lock it onto the camera’s Multi-function shoe connection with the lockable lever.

No need for batteries
The Multi-Function Shoe Adapter AD-E1 takes its power direct from the camera when attached for ease of use, allowing you to concentrate on the shot.

Small, discreet, lightweight
Weighing no more than a few grams the Multi-Function Shoe Adapter AD-E1 is lightweight and compact.

Mounting Foot
Type Multi-function
Number of Contacts 15
Locking Pins 2
Attachment Method Lever with locking mechanism
Water/Dust Resistance Supported
Mounting Shoe
Type Conventional hot-shoe
Number of contacts 5 pins (compatible with X-sync contact)
Locking Pins 1
Water/Dust Resistance Supported
Power Source
Power Source Powered by the camera
Included (Shoe) Cover
Physical Specifications
Dimensions (WxHxD) Approx. 38.8 x 31.7 x 38.4mm
Weight Approx. 41g (excluding cover)
Working Temperature 0 °C to 45 ºC
Working Humidity 85% or less

This product comes with 2 Years Warranty with Canon Australia. Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty. Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.

Canon AD-E1 Multifunction Shoe Adapter
Shoe Cap
