Zoom H4nSP Handy Recorder with Accessory Pack
Key Features

- Four-track simultaneous recording
- Supports up to 24-bit/96 kHz audio in WAV or MP3 formats
- Up to 11 hours of operation in Stamina mode with two AA batteries
24 Months Genuine Local Australian Warranty

$489.00 Incl. GST


  • Built-in X/Y stereo microphones
  • Four-track simultaneous recording
  • Supports up to 24-bit/96 kHz audio in WAV or MP3 formats
  • Up to 11 hours of operation in Stamina mode with two AA batteries
  • Records directly to SD and SDHC cards of up to 32 GB
  • Mounts directly to a tripod or DSLR with optional adapter
  • Auto-record and Pre-record features
  • Built-in reference speaker for fast monitoring
  • Variable playback speeds
  • Large 1.9-inch backlit LCD display
  • USB port for data transfer to computer
  • Product code FXR004P
  • 24 Months Genuine Local Australian Warranty

With the ability to render up to 11 hours of operation in Stamina mode with two AA alkaline batteries, the Zoom H4nSP Handy Recorder with Accessory Pack supports up to 24-bit/96 kHz audio in WAV or MP3 formats. This device records directly to SD and SDHC cards of up to 32 GB and it mounts directly to a tripod or DSLR with optional adapter. Audio is recorded through the built-in X/Y stereo microphones with four-track simultaneous recording and it can be reviewed using the built-in reference speaker for fast monitoring. This product also allows variable playback speeds and its functions can be viewed through the large 1.9-inch backlit LCD display. With auto-record and pre-record features, this item comes with a USB port for data transfer to computer and is tagged with product code FXR004P.

Product Features in Detail

Great on location
The H4n's onboard X/Y microphone delivers stunning stereo and its dual input combo connectors allow you to use your choice of external microphones as well. WAV files recorded with the H4n—up to 24-bit, 96 kHz—are automatically time-stamped to ensure perfect sync with your video footage, while built-in multi-effects and MS (Mid-Side) decoding gives you plenty of options in postproduction. With the use of our optional HS-1 Hot Shoe adapter, you can even mount the H4n directly to your camera.

Instant studio
The H4n transforms any rehearsal room into a recording studio. Connect mics and line level devices like electronic keyboards—even electric guitar or bass—and record up to four tracks of digital audio simultaneously, then bounce the tracks down to stereo or mono for additional overdubbing with no loss of quality.

Punch-in features and onboard effects such as compression, limiting, reverb, and guitar and bass amp modeling enable you to quickly and easily turn your musical ideas into full-fledged productions. You can even convert your finished song to an MP3 file for emailing and posting to your favorite social site.

Live Recording
Capture the sound of concerts, rehearsals, meetings, or lectures. The H4n's built-in X/Y microphone allows you to record natural-sounding stereo with a strong center image, and the angle of its two matched unidirectional mic elements can easily be changed from 90 degrees for a tightly focused stereo image to 120 degrees for a wider image.

In addition, dual combo XLR/TRS input jacks—complete with phantom power—allow you to use a wide variety of external microphones and to connect line-level signals such as a feed from a mixing board.

H4n Inputs and Outputs
Dual XLR/¼" combo input jacks allow you to connect microphones, line-level signals, or even instruments directly into the H4n. Phantom power of +24 or +48 volts can be applied to both inputs, allowing the use of condenser mics. There's also a secondary stereo ⅛" input for the connection of microphones requiring 2.5 volts of Plug-In Power.

A stereo ⅛" Line/Phone Out with dedicated volume control allows private monitoring over headphones as well as connection to the audio input of your DSLR—the H4n even has a built-in speaker for fast monophonic monitoring without the need to make any connections. In addition, a USB port allows recorded audio to be sent your favorite DAW and/or editing software and enables the H4n to act as a 2-in/2-out computer interface.

Pre-Record and Auto-Record
Pre-Record - The H4n's Pre-record function ensures that you'll never miss the start of a great take. It automatically keeps the H4n silently but continuously recording in the background, all the time, keeping the previous two seconds* of audio whenever you hit RECORD.

*One second when recording at 96k in 4CH mode.

Auto-Record - When enabled, Auto Record sets the H4n to automatically starts recording at a level of sound. An equivalent Stop function can be used to end recording as soon as incoming signal drops below a certain threshold.

Onboard Effects
Effects can make all the difference. They make your recordings sound professional and polished, and can be used both to enhance audio and to compensate for acoustic problems in the recording environment.

The H4n offers a variety of effects, ranging from compression and limiting to reverb, delay, echo, and a low-cut filter for the elimination of wind noise, pops and other kinds of unwanted low frequency noise. There's also an onboard metronome and tuner, along with dozens of effects crafted especially for guitar and bass, such as amp models. In addition, playback can be looped and the playback speed varied without pitch change (or vice versa), making the H4n perfect for phrase training.

File types supported
Audio recorded with the H4n is stored in your choice of WAV or MP3 format. WAV files are uncompressed and full fidelity, and thus provide optimum quality. The H4n provides support for 16 and 24-bit WAV audio at sampling rates of 44.1, 48, or 96 kHz. In addition, H4n WAV files are automatically time-stamped, making them Broadcast Wave Format (BWF) compliant, allowing precise synchronization in post-production.

MP3 recordings are compressed, removing unnecessary data so that they require less storage space and are easier to upload and download.

The H4n as an audio interface
A built-in USB port allows the H4n to serve as a 2-input / 2-output audio interface for any PC or Mac computer. Simply launch your favorite DAW or use the supplied Cubase LE software download, and start creating—you can even apply onboard effects to live incoming signal.*

*When operating at a 44.1k sampling rate

State of the art editing with every recorder
The Zoom H4nSP comes with free download licenses for Steinberg’s Cubase LE music production software and WaveLab LE audio editing software, providing not just the ability to capture superior audio in every box, but to do spectacular things with it.

Whether you wish to create your own music utilizing the Handy Recorder’s USB audio interface function or take your recordings to a more professional level, Steinberg’s powerful and state-of-the-art audio software used by creators around the world now comes with every Zoom Handy Recorder purchase.



Number of simultaneous recording tracks 2 (STEREO mode), 4 (4CH mode), 2 (MTR mode)
Number of simultaneous playback tracks 2 (STEREO mode), 4 (4CH mode), 4 (MTR mode)
Recording time 4GB (SDHC) Approx. 380 minutes (WAV 44.1 kHz/16 bit stereo track)
Approx. 68 hours (MP3 44.1 kHz/128kbps stereo track)
* Recording times are approximations. Actual times may differ according to recording conditions.
Maximum number of simultaneous recording files size 2GB
Projects 1000/card
Locate function Hours/Minutes/Seconds/Milliseconds
Other functions Punch-in/out, Bounce, A-B repeat
Effects modules 2
MTR Mode  PRE AMP module, EFX module
Types 50
Patches 60
Tuners Chromatic, Guitar, Bass, Open A/D/E/G, DADGAD
Metronome sound sources 5
Variable beat 1/4  -  8/4, 6/8, unaccentuated
Tempo 40.0 - 250.0 BPM
A/D conversion 24 bit × 128 oversampling
D/A conversion 24 bit × 128 oversampling
Recording media SD card (16MB - 2GB), SDHC card (4GB - 32GB)
Display 128 x 64 dots Full-dot backlit LCD


Quantization 16/24 bit
Sampling frequency 44.1 / 48 / 96 kHz


Bit rate 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 kbps, VBR
Sampling frequency 44.1 kHz


Bit rate 48, 56, 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 kbps, VBR
Sampling frequency 44.1 / 48 kHz


Input [1] [2] XLR (balanced input) / standard phone (unbalanced input) combo jack
Input impedance (Using balanced input) 1 kΩ balanced, pin 2 hot
(Using unbalanced input) 480 kΩ unbalanced
Input level (Using balanced input) −10 dBm to -42 dBm
(Using unbalanced input) +2 dBm to -32 dBm
Built-in stereo mic Unidirectional condenser microphone
Gain: +7 dB to +47 dB
External mic Mini stereo phone jack
Input impedance: 2 kΩ
Input level: -7 dBm to -47 dBm


Line/phone LINE Output load impedance: 10 kΩ or more
Rated output level: -10 dBm
PHONE: 20 mW+20 mW (into 32-Ω load)
Monaural speaker 400 mW 8 Ω
Phantom power 48 V, 24 V, OFF
USB USB 2.0 High Speed Mass Storage Class operation, Audio interface operation
(USB functions can be operated by USB bus power)
Power requirements DC 5 V 1A AC from AC adapter ( ZOOM AD-14)
Batteries IEC R6 ( size AA ) x 2
Continuous recording time 6 hours (STEREO/4CH/MTR mode)
11 hours (STAMINA mode)
Dimensions 73 (W) × 156.3 (D) × 35 (H) mm
Weight 280 g
  * 0 dBm = 0.755 Vrms * Design and specifications subject to change without notice.

This product comes with 24 Months Genuine Local Australian Warranty.
Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty.
Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.

In the Box

ECM-W1M Wireless Bluetooth Microphone for Cameras with Multi-Interface Shoe
H4nSP Handy Recorder
Hairy Windscreen
Hot Shoe Mount
Remote Control
Splitter Cable
Attenuator Cable
USB Cable
AC Adapter
2 x AA Battery
Download license for Steinberg Cubase LE and WaveLab LE
Operational Manual
24 Months Genuine Local Australian Warranty
