Pulsar Axion 2 LRF XG35 Thermal Monocular

A$4,499.00

Check Stock

Please contact us to check the ETA for this product

Free Shipping for Orders over $98* (*excludes bulky items)
No SURCHARGE FOR CREDIT CARDS
  • Compact and lightweight
  • Functional and ergonomic design
  • 8-colour display palette
  • 3 calibration modes: Manual, Semi-Automatic, Automatic
  • Three levels of sensitivity enhancement: Normal, High, Ultra
  • Stadiametric Rangefinder
  • Display-Off function
  • Defective pixel repair
  • Updatable firmware
  • Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
  • Fully waterproof (IPX7 rated)
  • Tripod mount

The Pulsar Axion 2 LRF XG35 Thermal Monocular is an advanced, highly portable device built for clarity and convenience in thermal imaging. Designed to meet the demanding needs of outdoor enthusiasts, security personnel, and hunters, this monocular combines high-performance imaging qualities with a durable, user-friendly build. The device is built for ease of transport and use, even over extended periods, making it ideal for situations requiring mobility and discretion. Its design maximizes user comfort and efficiency, ensuring that all controls are easily accessible for users on the move or in the dark. This monocular has 8-colour display palette that offers users the option to choose from eight distinct color palettes for optimal viewing across various environments and scenarios. This feature enhances the ability to detect heat signatures under different conditions. Manual, Semi-Automatic, and Automatic modes allow users to balance image quality with operational simplicity, ensuring clear viewing in varying thermal environments. With Normal, High, and Ultra settings, users can adjust the device's sensitivity to improve the clarity and range of thermal detection, crucial for identifying subjects at varying distances and environmental conditions.

The stadiametric rangefinder functionality facilitates distance measurement to observed objects, a critical tool for hunting, surveillance, and reconnaissance. The display-off function allows users to conserve power by turning off the screen without shutting down the entire device, enabling quick restart and continuous observation without missing critical moments. Defective pixel repair ensures the longevity and quality of the display by allowing users to address dead or stuck pixels, a valuable feature for maintaining optimal image quality over the lifespan of the device. Updatable firmware keeps the monocular current with the latest software enhancements and capabilities, ensuring that the device remains at the cutting edge of thermal imaging technology. Wide operating temperature range (-25°С to +40°С / -13°F to +104°F) guarantees reliable operation in extreme conditions, from freezing temperatures to hot environments, making it suitable for all-year-round use. A fully waterproof IPX7 rate ensures the device's performance in wet conditions, protecting it against heavy rainfall or accidental submersion. A tripod mount provides added stability for long-duration observation, reducing hand fatigue and enhancing image clarity by minimizing hand-shake effects.

The Pulsar Axion 2 LRF XG35 Thermal Monocular delivers a robust set of features tailored for serious outdoor, surveillance, and hunting applications. Its compact form, combined with a range of imaging and operation features, makes it an excellent tool for those requiring reliable thermal imaging in a portable, durable package. Whether used for nature observation, security purposes, or hunting, the Axion 2 LRF XG35 offers quality and performance in a wide array of environmental conditions.


Product Features in Detail



Pulsar Axion 2 LRF XG35
The Pulsar Axion 2 LRF XG35 is a favorite of hunters who require a bigger resolution and precise distance measurements.


European-made Lynred sensors

The Axion 2 thermal monoculars are equipped with European Lynred sensors with either a resolution of 384×288 pixels (17 µm pixel pitch) or 640×480 pixels (12 µm pixel pitch), which qualitatively capture a useful signal under difficult observation conditions, such as rain, fog and high atmospheric humidity at the observation site.


Long-distance laser rangefinder
Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder with a range of up to 1 kilometre allows you to measure distances in single measurements and continuous scanning modes with an accuracy of ± 1 meters for quick and error-free assessment of the situation.


High-quality reinforced magnesium alloy housing
Axion is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold. At the same time, a metal housing effectively removes the heat from electronics, minimizes image noise and increases consistency of the device operation during long-term observation.


Fast aperture F35/1.0 lens
F35/1.0 lens features high infrared transmission in the LWIR range. Due to the high precision manufacturing of the optical elements of the lens, the image generated by the Axion 2 thermal imaging device sensor is distinguished for its clarity and detailing.


Extended battery life. Up to 11 hours on a single charge
A high-capacity APS5 rechargeable battery provides up to 11 hours of continuous operation of the thermal imaging device on a single charge. The battery is removed from a battery housing and replaced with a new one in seconds. The battery is charged in a special charger or inside the device from a PC, household power system or power bank via USB-C. The same sources are used for external power supply of a thermal imaging device.


Detection range up to 1750 m
A powerful F35/1.0 objective lens combined with a highly-sensitive thermal imaging sensors provide exceptional detection capabilities. A standard 1.8m tall object can be detected up to 1750 m away in complete darkness.


Pocket-sized dimensions and light weight
Axion 2 LRF has a space-saving and pocket-sized design and weighing 350 grams. The device is easy to grip and operate by right-handed and left-handed people due to the symmetrical design and in-line buttons arrangement on the upper panel.


Dual Wi-Fi waveband support 2.4 / 5 GHz
In Axion 2 thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz WiFi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.


3 levels of sensitivity amplification
Each Axion 2 thermal imaging monocular uses a new approach to image optimisation depending on the purposes and conditions of observation and provides high-quality rendering of both target objects and background. Three levels of signal amplification in combination with a connected smoothing filter and fine brightness and contrast adjustments give the hunter great opportunities for long-range detection of the animal under different weather and temperature conditions and determining its trophy qualities.

Main specifications
Sensor @ 12 µm 640x480
Objective lens F35 / 1.0
Magnification, x 2.5 – 20 (x8 digital zoom)
FOV (HxV), degrees 12.5 x 9.4
FOV (HxV), m@100m 21.9 x 16.5
Detection range 1750 m
Sensor
Type uncooled
Resolution, pixels 640x480
Pixel pitch, µm 12
Sensor NETD, mK < 40
System NETD, mK < 20
Frame rate, Hz 50
Optics
Objective lens F35 / 1.0
Magnification, x 2.5 – 20 (x8 digital zoom)
FOV (HxV), degrees 12.5 x 9.4
FOV (HxV), m@100m 21.9 x 16.5
Eye relief, mm 14
Display
Type AMOLED HD
Resolution, pixels 1024x768
Range performance
Detection range, m 1750 m
Laser rangefinder
Max. measuring range, m 1000
Measurement accuracy, m ± 1
Safety class for laser equipment according to IEC 60825-1:2014 1
Wavelength, nm 905
Video recorder
Video / photo resultion, pixel 1024x768
Video / photo format .mp4 / .jpg
Build-in memory, GB 16
WI-FI
Wireless protocol Wi-Fi
Wireless standard IEEE 802.11 b/g/n/ac
Frequency, Ghz 2.4 / 5
Environmental characteristics
Degree of protection IP code (IEC60529) IPX7 (waterproof)
Operating temperature range, °С -25 – +40
Connections and compatibilities
Mount type 1/4"
Supported application Stream Vision 2
Power supply
Output voltage, V 3.0 – 4.2
Battery type APS 5 Li-ion Battery Pack
Capacity, mAh 4900
Operating time on battery pack, h at t=22°С 7
External power supply, V 5V; 9V (USB Type-C Power Delivery)
Weight & size
Body material Magnesium alloy
Dimensions, mm 152x74x75
Weight, kg 0.43

This product comes with 12 Months Australian Manufacturer Warranty. Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty. Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.

Pulsar Axion 2 LRF XG35 Thermal Monocular
Axion 2 LRF thermal monocular
APS 5 rechargeable battery
2 battery-locking covers
Power adapter
USB Type-C cable with USB Type-A adapter
Carrying case
Hand strap
Quick reference user manual
Lens cleaning cloth
Warranty information
Tripod adapter
