Olympus PRO 12-45mm f/4 Lens
- Micro Four Thirds System
- 24-90mm (35mm Equivalent)
- f/4 to f/22 Aperture Range
- Standard wide-angle to portrait-length zoom lens
- ZERO (Zuiko Extra-low Reflection Optical) coating
- 2 aspherical elements and one DSA (Dual Super Aspherical) element
- 2 extra-low dispersion elements, one Super HR (high-refractive index) elements
- 2 HR elements
- Minimum focusing distance of 4.7"
- Dust, freeze, and drip-proof design
- Rounded seven-blade diaphragm
Featuring the Micro Four Thirds Olympus PRO 12-45mm f/4 Lens. A standard wide-angle to portrait-length zoom lens dedicated for use in customizing the settings especially on image focusing. It has a 24-90mm (35mm Equivalent) focal range plus f/4 to f/22 Aperture Range and comes with a minimum focusing distance of 4.7". The lens construction includes 2 aspherical elements and one DSA (Dual Super Aspherical) element, 2 extra-low dispersion elements, one Super HR (high-refractive index) elements, and 2 HR elements that helps minimize distortion, aberrations, and color fringing bringing superb image sharpness, clarity, and color accuracy. This lens is dust, freeze, and drip-proof to ensure long lasting use.
Product Features in Detail
This is the world's most compact, lightweight lens among standard zoom lenses with a fixed aperture value. The lens features superb portability so the camera can be stored in your usual bag or hung from a neck strap when out and about for easy, comfortable shooting. When viewing the entire system with combined lens and camera body, it is approximately 70% the volume and approximately 62% more compact and lightweight than a full-frame interchangeable lens camera system, bringing out the best of the Micro Four Thirds System.
The World's Smallest and Most Lightweight Model
The lens is 63.4 x 70 mm (max. diameter x length) in size, and weighs a mere 254 g. The world's most compact, lightweight* design was achieved by precision machining of 190 components, and carefully mounting each and every one in a dense configuration on the lens.
Compact, Lightweight System
When pairing the M.Zuiko Digital ED 12-45mm F4.0 PRO with the OM-D E-M5 Mark III, the entire system is approximately 113.3 mm long, and weighs nearly 668 g. Compared to a full-frame mirror-less camera with attached standard zoom lens that covers an equivalent focal length, it is approximately 70% less in volume and approximately 62% lighter.
Dustproof, Splashproof and Freezeproof
Sealing is included on nine of the lens for a dustproof and splashproof construction. When paired with a dustproof and splashproof performance camera body, you can shoot high image quality images with peace of mind in the harsh environments.
In order to enable speedy AF, a compact, lightweight focusing lens design was adopted. When combined with the high-performance AF system of a camera such as the OM-D E-M5 Mark III, this lens is capable of fast, accurate focusing when shooting moving subjects.
A compact, lightweight design and high image quality are achieved thanks to advanced optical technology. The lens delivers high resolution imaging at all focal lengths from 24 mm to 90 mm (35mm equivalent).
Lens Configuration for Sharp Imaging
This lens basic optical configuration inherits from M.ZUIKO DIGITAL ED 12-40mm F2.8 PRO that is a well-recognized lens for its high resolution. Using special lenses such as ED lenses, DSA lens, and Super HR lenses in an effective layout for sharp imaging across the entire zoom range and frame. ZERO Coating is also applied to the appropriate lenses to reduce ghosts and flares.
Fixed Wide-aperture Across the Entire Zoom Range
A maximum aperture of F4.0 is achieved across the entire zoom range, from wide angle to telephoto shooting. Because the aperture value remains the same at any focal length, the exposure is easily kept stable while using the zoom in your shots.
Bright and Clear to the Edges
This lens suppresses peripheral light loss, resulting in bright, clear depictive performance to the edges of the frame.
Superb Macro Capabilities
An optical design that favors macro capabilities is utilized in this lens for amazing close-up photos when shooting right next to subjects.
Maximum Shooting Magnification of 0.5x across the Entire Zoom Range (35mm Equivalent)
The closest focusing distance is 12 cm at the wide-angle end and 23 cm at the telephoto end. Capture a range of 69.2 x 52 mm at a maximum image magnification of 0.5x (35mm equivalent) across the entire zoom range.
Versatile Macro Expressions
This single lens is capable of wide-angle macro shots that emphasize a sense of perspective by capturing vast backgrounds, and tele-macro shooting for more significant background defocusing effects. With this, you can enjoy a diverse array of macro expressions that perfectly suit your shooting style.
8 photos are captured at different focal positions and automatically composited into a single photo. Capture a photo with a large depth of field that is in focus from the foreground to background.
|Focal Length||12-45 mm (35 mm Equivalent Focal Length: 24-90 mm)|
|Lens Construction||12 elements in 9 groups (2 HR lenses, 1 DSA lens, 1 Super HR lens, 2 Aspherical lenses, 2 ED lenses)|
|Splashproof Type / Dustproof||IEC Standard publication 60529|
|IPX1 (applies when the lens is used with Olympus splashproof Body) /|
|Angle of View||84 degrees (Wide) - 27 degrees (Tele)|
|Closest Focusing Distance||0.12 m (wide) / 0.23 m (tele)|
|Maximum Image Magnification||0.25x (Wide / Tele)|
|35mm Equivalent Max. Image Magnification||0.5x (Wide / Tele)|
|Minimum Field Size||69.2 x 52.0 mm (Wide / Tele)|
|Number of Blades||7 (Circular aperture diaphragm)|
|Filter Size||Diameter 58 mm|
|Dimensions||Ø63.4 x 70.0 mm|
Olympus PRO 12-45mm f/4 Lens
Lens hood LH-61G
Lens cap LC-58F
Lens rear cap LR-2
Wrapping cloth CS-53
