The Lynx Pro LE10 thermal imager is the most compact and lightweight portable thermal imager on the market today. It’s perfect for first responders, law enforcement and anyone who wants a professional level tool without the bulkiness of a larger model.

This unit has a built-in 256×192 sensor that gives you a 12 μm resolution, giving you sharp images at long distances. Its 4× digital zoom allows you to see even more detail when you need it. The Lynx Pro LE10 comes with an easy to use interface that allows you to change settings quickly and easily.

This model also features a 458 m detection range and 0.2 inch LCD screen with backlight. This allows you to easily read images in bright light conditions or complete darkness. The Lynx Pro LE10 also comes with an auto shut off feature after 30 minutes of no use, saving battery life while not in use.

The Lynx Pro LE10 features Smart Range Measurement (SRM) technology which automatically sets your distance based on the object size and temperature difference between it and its surrounding area. You don’t have to worry about manually entering measurements or setting up markers anymore!

Product Features in Detail

Advanced VOx 12 μm Imaging Sensor
LYNX PRO series carries the new VOx 256x192/384x288 12 μm sensor (less than 35mK), and large aperture lens, which gives a clear picture of the target even in complete darkness.

Long Detection Range
With the advanced imaging sensor and lens, detection range of a 1.7m target can reach up to 1181 m.

Video & Snapshot
Onboard 8GB memory offer storage space for the snapshots and videoclips. Recorded files can be downloaded when connected to PC via USB port.

Wi-Fi Hotspot for Mobile App
Integrated wi-fi module makes T-Vision app as a second display. Users can use digital zoom, video recording, and other features on their phones.

Standby Mode
Designed to save power consumption with the screen off while other features on. The device can be activated in a short time by pressing the button.

4 Colour Palletes
Provides 4 colour palletes for different scenarios

Smart Range Measurement
Measuring distance quickly with high accuracy based on the top and bottom of the target

Large Digital Zoom
Digital zoom up to 8x offers a better focus on small targets from a far distance

Specification

Sensor	256×192, 12μm
NETD	Less than 35 mK (25 °C,F#=1.0)
Focal Length	10 mm, F1.0
Magnification	1.00 – 8.00
Field of View	18.0° × 13.6°
Detection Range	458m
Manual Focus	No
Digital Zoom	1×, 2×, 4×, 8×
Monitor	0.2 inch, LCOS, 720 × 540
Battery Type	Build-in rechargeable Lithium battery
Wi-Fi	Yes, Hotspot
Record/Snapshot	Yes
Operating Time	Up to 8 h
Dimension	158.3×61×57 mm
Weight	260g
IP Rating	IP67
Operating Temp.	-20°С ~ +55°С

Warranty

This product comes with Australian HIKMICRO Warranty. Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty. Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.

In The Box

HIKMICRO Lynx Pro LE10 Thermal Imaging Monocular
