- Canon XF300 Video Camera
The Canon XF300 is the newest professional digital video camera for event videographers and film makers. The video camera has been designed around feedback from professional camera operators. It features 1/3 inch 3CMOS Sensor System, 50Mbps MPEG-2 Recording, 50Mbps MPEG-2 Recording with 270° rotation and High Resolution, 1.55MP Viewfinder. This camcorder holds a 4.0 inch 16:9 ratio wide screen LCD screen with 1.23m dot Viewfinder enabling the detailed shooting. Its 3 Modes SuperRange Optical Image Stabilization system will make your images free from blur.
Product Features in Detail
Professional video perfection
The XF300 - Canon’s latest professional digital video camera for event videographers, film makers and news gatherers - is truly state of the art. Designed through feedback from professional camera operators, the XF300 is also very mobile, with excellent balance between operation and weight.
Capture high quality HD to CF cards
The XF300 records MPEG-2 MXF (Media eXchange Format) files – up to 1920 x 1080 Full HD at 50Mbps (4:2:2) – to CompactFlash (CF) memory cards. CF media is inexpensive and widely available: dual card slots allow filming to continue without interruption.
Integrating seamlessly with existing workflows, movies shot on the XF300 are captured as industry-standard MXF files compatible with all major editing packages.
18x wide-angle lens
Drawing on Canon’s broadcast lens expertise – and informed by the feedback of professionals – the lightweight 18x L-series HD Video Lens delivers superb optical quality. Unique Ultra-Low Dispersion (Hi-UD) elements are used to prevent chromatic aberration. Separate rings offer independent control of Focus, Zoom and Iris (F1.6) – with full manual control available, end stops are provided for the focus and zoom rings.
3x Full HD CMOS
Full HD at 1920 x 1080 resolution is captured via three 1/3 type 2.07 Megapixel Full HD CMOS sensors – designed and manufactured by Canon in-house. High speed scanning minimises the effects of a rolling shutter.
10.1 cm LCD and 1.3 cm EVF
The 10.1 cm (4”) LCD screen can be positioned either side of the camera. Offering superior resolution (1.2M dots), the Focus Assist tool helps achieve sharp images. A built-in Waveform Monitor (WFM) helps verify exposure and other shooting parameters. Alternatively, a 1.3 cm (0.52”) Electronic Viewfinder (EVF) is available.
Variable frame rate
A wide range of frame rates is available, from 12 to 50 fps. This gives cameramen the freedom to alter the capture rate for additional creative flexibility.
Audio can be captured via twin XLR inputs and also with the front-mounted stereo microphone.
Twenty-six Custom Picture options can be adjusted to achieve the perfect look. These can be stored in-camera – via SD card - and settings can even be transferred between camcorders.
|Movies: CF Card Type I only (2 Slots), UDMA4 recommended; Stills: SDHC/SD|
|1/3 inch 3CMOS|
|DiG"C DV III|
|Movie Compression System|
|MPEG-2 Long GOP 4:2:2 (50 Mbps)|
|1920 x 1080|
|Focal Length (nominal)|
|4.1 . 73.8mm|
|Focal Length (35mm equivalent)|
|Approx. 29.3 . 527.4mm|
|f/ 1.6 . 2.8|
|Provided (electronic ring); either [AF/MF] mode with no rotational limit or [FULL MF] mode with rotational limit and distance indicator can be selected.|
|Provided (electronic ring). Focal length indicator, zoom limit provided. Manual zoom/Power zoom.|
|One of three settings (Slow, Normal or Fast) can be selected for the power zoom mode and, in each mode, either a variable speed (16 steps) or fixed speed (16 steps) can be set.|
|Provided (electronic ring)|
|6 iris aperture leaves, material used: Metal (treated for immunity from sunlight-induced burns)|
|Close up distance|
|1 m (entire zoom range), 20 mm with wide macro|
|Optical system (lens shift system adopted/Super range system support)|
|Zoom/focus preset function|
|One push AF function|
|3 steps of ND1 (ND: 1/4), ND2 (ND: 1/16), ND3 (ND: 1/64)Material used: Glass (treated for immunity from sunlight-induced burns)|
|Filter diameter and pitch|
|82 mm / P0.75 mm|
50 Mbps CBR (4:2:2) [[email protected]]
|1920 x 1080PAL . 50i / 25P1280 x 720PAL . 50P / 25P|
|35 Mbps VBR (4:2:0) [[email protected]]|
|1920 x 1080PAL . 50i / 25P1280 x 720PAL . 50P / 25P|
|25 Mbps CBR (4:2:0) [[email protected]]|
|1440 x 1080PAL . 50i / 25P|
Light Metering Method
|Centre-weighted / Spot / Backlight Correction|
|White Balance Mode|
|AWB, Set (2 positions). Preset (Daylight/Tungsten), Colour Temperature (2,000K . 15,000K)|
|3.8 Lux (shutter speed 1/50 sec), 0.05 Lux (shutter speed 1/3 sec)|
|LCD / Viewfinder||
View Screen / Pixels
|4.0 inch 16:9 ratio wide screen LCD screen (1,230,000 dots), 100% coverageAngle adjustment enabled with high, low angle support and self portrait shooting possibleBrightness, contrast, colour, sharpness and backlight adjustment|
|0.52 inch 16:9 ratio wide screen LCD screen (1,555,000 dots), 100% coverageAngle adjustment enabled.+2.0 to -5.5 diopter, 3-lens configurationBrightness, contrast, colour, sharpness and backlight adjustment|
|Filming Models & Controls||
|Auto / 50i / 25P|
|Special Recording Modes|
|Frame Rec, Interval Rec, Slow & Fast Motion, Pre-Rec|
|Linear PCM (16-bit, 48KHz), 2-ch|
|Audio Level Metering|
|Manual audio level VR metering & control|
|Wind Low-Cut setting x2|
|Still Image Recording||
|Memory Card Type|
|SDHC / SD slot|
Input Power Supply
|7.4 V DC (Battery Pack), 8.4 V DC (DC IN)|
|Input Signals:XLR 3-pin jackOutput Signals:HDMI (Type-A)USB (mini-B, USB 2.0 Hi-Speed)AV (3.5mm, 4-pole mini-jack)ComponentHeadphone (3.5mm Stereo mini-jack)Remote (2.5mm Stereo mini-jack)Video2 terminal (BNC Connector)|
|Canon XF Utility -PC: Windows XP SP2/SP3 (32-bit), Vista SP1/SP2 (32/64-bit), Windows 7(32/64-bit)Mac: OS X 10.4 to 10.6|
Dimensions W x H x D
|153 x 236 x 382mm|
|Weight exc. battery (g)|
This video camera comes with 12 Months Warranty from Canon Australia.
Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty.
Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.
Canon XF300 Video Camera
Battery Pack BP-955
Compact Power Adapter CA-930
DC Cable DC-930
Wireless Controller WL-D6000
Shoulder Strap SS-1200
Component Cable DTC-1500
Canon XF Utilities Disc
12 Months Warranty with Canon Australia
