Yololiv YoloBox Extreme All-in-One Multi-Camera Live Streaming and Switching System

A$3,599.00

Check Stock

Please contact us to check the ETA for this product

Free Shipping for Orders over $98* (*excludes bulky items)
No SURCHARGE FOR CREDIT CARDS
  • Simultaneous Cross-Platform Streaming
  • Qualcomm Snapdragon 8 Gen2
  • 8 HDMI and 6 NDI Inputs
  • 2 HDMI Outputs, 2 USB Inputs
  • Encoder, Monitor, Switcher & Recorder
  • Built-In Audio Mixing
  • SD Card Slot, Nano SIM Card Slot
  • HDMI, NDI, USB-C & USB-A Inputs
  • Up to UHD 4K Video, ISO Recording
  • Stream via Ethernet, Wi-Fi 7, 4G Network
  • 11.2" OLED Touchscreen, External Antenna
  • Live Switch Between 20 Sources
  • Up to 10 Hours of Battery Life

The Yololiv YoloBox Extreme is an advanced, all-in-one multi-camera live streaming and switching system designed to offer content creators, live event producers, and broadcasters a comprehensive and portable solution for managing and sharing live video content. It features simultaneous cross-platform streaming that allows users to stream content to multiple platforms like YouTube, Facebook Live, Twitch, and other streaming services concurrently, expanding the reach and accessibility of the live broadcast. A powerful Qualcomm Snapdragon 8 Gen2 mobile processor provides the YoloBox Extreme with high processing power for live encoding and multitasking, ensuring a smooth streaming experience. The device offers a total of 14 video inputs with 8 HDMI and 6 Network Device Interface (NDI) sources, providing flexibility in connecting a variety of cameras and devices for a multi-angle live production. With multiple outputs, the YoloBox Extreme can send the live mix to different displays or recording devices, while USB inputs expand connectivity with devices like webcams or USB storage.

The unit combines the functionality of an encoder for live streaming, a monitor for viewing the live feed, a switcher for changing between video sources, and a recorder for capturing the live stream on an SD card. Built-in audio mixing allows users to control and mix audio sources directly from the YoloBox, ensuring the broadcast sound is well-balanced and professional. The SD card slot provides local recording capability, while the Nano SIM card slot enables streaming over 4G LTE networks when a wired or Wi-Fi connection is unavailable or unreliable. Diverse input types allow for a wide range of connectivity options for video sources and data transfer. The device supports ultra-high-definition video for streaming and recording, and ISO recording means that individual video inputs can be recorded separately for post-event editing. Multiple connectivity options ensure a stable streaming experience, whether tethered with Ethernet, wirelessly over the latest Wi-Fi protocol, or through mobile networks using a 4G connection. The large 11.2" OLED touchscreen provides a clear interface for managing the stream, switching views, and monitoring the production, while the external antenna improves wireless connectivity. Live switch between 20 sources enables users to switch live between up to 20 different video sources—even combining HDMI and NDI sources—during a broadcast. The impressive battery life ensures that the YoloBox Extreme can handle extended live streaming sessions without needing external power.

The Yololiv YoloBox Extreme is a robust and versatile live streaming platform that packs a suite of production tools into one portable device. It simplifies the complexity of multi-camera live streaming setups and suits a wide range of professional applications, from broadcasting sports events to streaming live concerts, or webinars. With its potent combination of connectivity, performance, and ease of use, the YoloBox Extreme establishes itself as a powerful all-in-one solution for live content creators who require quality, reliability, and flexibility.


Product Features in Detail



All-In-One
Encoder, switcher, recorder, monitor, in One


Android System
Users can benefit from regular updates while enjoying an intuitive and familiar interface that enhances usability.


Minimum Setup
No computer/desk workstation/professional crew required


Portability & Mobility
Compact size, fit into your backpack, live On the Go.


Battery-Powered
10 Hour Battery Life + Built-In 4G LTE, WiFi, Ethernet


Touchscreen Control
Production at your fingertip, great ease to operate


8 HDMI Input - More is Better
Connect Cameras, Laptops, Media Players, and More, Offering Unmatched Flexibility for Any Scenario. Future-Proof Your Setup Without Worrying About Running Out of Ports.


Dual Assignable HDMI Outputs
Allowing You to Output Different Video Feeds( Preview, Multiview or Program) Simultaneously.


More Space to Explore
The all-new 11.2-inch OLED screen brings a larger, more immersive display, redefining how you see and interact with content.


Shine in Any Light
With a peak brightness of up to 800-1,000 nits, every detail remains vivid and clear, even under direct sunlight.


Effortlessly Responsive
Enjoy ultra-fast touch feedback for a silky-smooth experience, making every interaction seamless and intuitive.


Live Switch
Easily switch between multiple video sources or fully customized scenes with a touch.


Audio Mixing
Built-in audio mixer with easy setup. Individual level control of multiple audio sources.


ISO Recording
Capture all the video inputs as well as the program video and save them separately.


Graphic Overlays
Add logos, lower thirds, titles, countdown timer and more to look professional.


MultiViews
Customize live stream layout with built-in multiviews and level up production with ease.


Scoreboard
YoloBox’s built-in scoreboards allow you to keep the score in real-time, display game progress, add game/team logos, and more.


MultiCam Replay
Create highlight clips with preset video duration, intros, outro and more with a few clicks.


Inviting Guests
Create a real-time conversation with remote guests from a web browser on mobile devices.


PTZ Control
With PTZ control, you can preset up to 5 camera positions. This allows you to quickly switch between different angles and views.


Crop Video
Video cropping serves various needs such as margin removal, game capture resizing, conferencing zooming, and close-up view creation.


Chroma Key
Seamlessly add a different background of a design or a different location for your live productions with the magic of chroma key in a few taps.


AutoSwitch
Seamless Transition between pre-set camera angles with defined order and duration. Frees you from manual camera control to focus on the video.


Create Multiview Layouts in Seconds, Not in Hours
Quickly add multiviews to enhance your workflow with the built-in templates like Side By Side, Picture in Picture, 3 Views, and customized Layout. Boost your productivity right at your fingertips!


Assignable AFV
Each audio channel automatically switches as the video changes, ensuring perfect synchronization.


Mix Minus
Easily solo monitor a specific audio channel or mute it entirely, giving you full control.


Audio Delay
For any sync issues between audio and video, simply adjust the timing to ensure synchronization.


Director Mode
The newly added "Director Mode" features full-size Preview & Program, making it easier to check video sources before switching. It also allows quick customization of transitions and durations.

Dimensions & Weight Height: 29mm
Width: 167 mm
Length: 264 mm
Weight: ≈ 1500g
Input Power 9V / 12V / 15V⎓3A
Power Consumption 45W
Power Supply USB Type-C
USB Rated Output USB-A:5V/1A
Battery Capacity 10000mAh
Dimensions 264*167*29mm
Power Consumption <45W
Monitor Screen Size 11.2inch 2K OLED; Resolution: 2560x153;
Brightness: 450nits ( ≈ LCD 800-1000nits);
Frequency: Fre =120Hz; Contrast ratio (1500:1);
Viewing Angle (full viewing Angle); NTSC 108%
Local Video Inputs HDMI USB-A
Video Over Ethernet RTMP/RTMPS/SRT/NDI/RTSP
Video Input Connectors HDMI, USB-A, RJ-45, USB Type-C
Video Input Aspect Ratios 16:9, 4:3, 1:1
Video Input Deinterlacing No
Live Broadcast Video Input Resolution 480p/720p/1080p(up to 60fps)/4Kp60
Video Encoded Format H.264 H.265
Video Processing Bitrate Control CQ, VBR, CBR
Hardware-accelerated Video Encoding Optional
Video Output Signal Types FLV-RTMP, HDMI, UVC
Video Output Connectors HDMI OUT, USB-C
Video Output Streaming Protocols RTMP, RTMPS, MJPEG, SRT
Live Broadcast Video Output Resolution 480p/720p/1080p(Up to 60fps)/4Kp60
Analog Audio Input Connectors Line In; Mic In; 3.5mm
Digital Audio Outputs USB; HDMI; RTMP (From internet);
Local video (From SD card)
Digital Audio Input Connectors USB-A, HDMI, USB-C
Audio Input Mute Yes
Audio Input Format 32KHZ/44.1KHZ/48KHZ :16bit
Audio Encoded Format (AAC)44.1K/48KHZ 2Ch 16bit
Analog Audio Output 3.5mm Headphone Jack
Digital Audio Outputs HDMI Audio (Embedded); USB Audio (Embedded)
Record Formats MP4
Wi-Fi 2.4G/ 5G (Support WiFi6/WiFi7)
USB Communication Standard USB 2.0 and USB 3.0
Ethernet Data Rate 10/100/1000m, Half/full Duplex With Autodetect
SIM Card Size Nano-SIM Card
4G Network 4G Network Countries & Frequency Band For
Users: [Variant for North Americao (US/Canada/Mexico)]
B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B41/B66/B71
Notes: Mexico B4 For Non-US/Canada/Mexico
Users: (EU:Variant for EMEA/India/Korea/Taiwan/South
Asia/Latin/America/Australia/New Zealand)
Users:B1//B3/B7/(B8) Notes:Thailand B1/B3

Please note that the certification of Yolobox Extreme is in line with the mainstream open 4G band requirements of operators in this country or region. For details, please refer to the approval report of this country or region.
SD Card Format FAT32(Under 128G); NTFS; EX-FAT
Operating Temperature 0℃-40℃
Operating Humidity 15%-85%; No Condensation
Country of Origin Made in China
YoloBox Extreme TH
WCDMA Network B1/B8
4G Network B1/B3/B7/B8
USB Communication Standard USB 2.0 and USB 3.0
Ethernet Data Rate 10/100/1000M, half/full duplex with autodetect
SIM Card Size Nano-SIM Card
SD Card Format FAT32(Under 128G), NTFS, EX-FAT
Operating Temperature 0℃-40℃
Operating Humidity 15%-85%, No Condensation
Country of Origin Made in China

This product comes with 12 Months Australian Manufacturer Warranty. Our products are sourced from authorised Australian suppliers and therefore come with genuine Australian warranty. Camera Warehouse does not participate in 'Grey Market' or 'Parallel Import' activities.

Yololiv YoloBox Extreme All-in-One Multi-Camera Live Streaming and Switching System
Power Adapter
USB-C Cable
USB-A to USB-A Cable
Cold Shoe Mount Adapter
2 x Antenna
SIM Card Eject Pin
International Plug Adapter Set
Allen Key
