Type
|
| Type |
Digital interchangeable lens system camera |
| Recording media |
SD memory card, SDHC memory card, SDXC memory card |
| Image sensor size |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Lens mount |
Micro Four Thirds mount |
Image Sensor
|
| Type |
Live MOS Sensor |
| Total Pixels |
16.68 Megapixels |
| Camera Effective Pixels |
16.0 Megapixels |
| Colour Filter |
Primary color filter |
| Dust Reduction System |
Supersonic wave filter |
Recording System
|
| Recording file format |
Still Image: JPEG(DCF, Exif 2.3), RAW, DPOF compatible
MPO (When attaching 3D lens in Micro Four Thirds standard) |
| Aspect ratio |
4:3, 3:2, 16:9, 1:1 |
| Image quality |
RAW, RAW+Fine, RAW+Standard, Fine, Standard,
MPO+Fine, MPO+Standard (with 3D lens in Micro Four Thirds System standard) |
| Color space |
sRGB, Adobe RGB |
| File Size Pixels (Still Image) |
[4:3] 4592x3448(L)[16M] / 3232x2424(M) [8M] / 2272x1704(S) [4M] / 1824x1368(When attaching 3D lens in Micro Four Third System standard)
[3:2] 4576x3056(L) [14M] / 3232x2160(M)[7M] / 2272x1520(S)[3.5M] / 1824x1216(When attaching 3D lens in Micro Four Third System standard)
[16:9] 4576x2576(L) [11.5M] / 3232x1824(M) [6M] / 1920x1080(S) [2M] / 1824x1024(When attaching 3D lens in Micro Four Third System standard)
[1:1] 3424 x 3424 (L) [11.5M] / 2416 x 2416 (M) [6M] / 1712 x 1712 (S)[3M] / 1712x17 |
| File Size Pixels (Motion Picture): Motion JPEG*1 |
[4:3] QVGA : 320 x 240, 30fps / VGA : 640 x 480, 30fps
[16:9] HD : 1280 x 720, 30fps |
| File Size Pixels (Motion Picture): AVCHD*2 - NTSC |
[Full HD] 1920×1080, 60i (sensor output is 30p) (FSH:17Mbps)
[HD] 1280 x 720, 60p (sensor output is 30p)(SH:17Mbps) |
| File Size Pixels (Motion Picture): AVCHD*2 - PAL |
[Full HD] 1920×1080, 50i (sensor output is 25p) (FSH:17Mbps)
[HD] 1280 x 720, 50p (sensor output is 25p)(SH:17Mbps) |
| Continuous recordable time (Motion images) |
AVCHD with picture quality set to [FSH]: Approx. 110 min with H-FS014042 / Approx. 100 min with H-FS045200
Motion Jpeg with picture quality set to [HD]: Approx. 120 min with H-FS014042 / Approx. 110 min with H-FS045200 |
| Actual recordable time (Motion images) |
AVCHD with picture quality set to [FSH]: Approx. 55 min with H-FS014042 / Approx. 50 min with H-FS045200
Motion Jpeg with picture quality set to [HD]: Approx. 60 min with H-FS014042 / Approx. 55 min with H-FS045200 |
Focus
|
| Type |
Contrast AF system |
| Focus mode |
AFS/ AFC/ MF |
| AF mode |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint |
| AF detective range |
EV 0-18 (ISO100 equivalent) |
| AF assist lamp |
YES |
| AF lock |
Set the Fn button in custom menu to AF/AE lock |
| Others |
Quick AF, Continuous AF (during motion image recording), AF+MF, Touch shutter, Touch MF Assist |
Exposure Control
|
| Light metering system |
144-zone multi-pattern sensing system |
| Light metering mode |
Intelligent Multiple / Center Weighted / Spot |
| Metering range |
EV 0 - 18 (F2.0 lens, ISO100 equivalent) |
| Exposure mode |
Program AE, Aperture Priority AE, Shutter Priority AE, Manual |
| ISO sensitivity(Standard Output Sensitivity) |
Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 (Changeable to 1/3 EV step) |
| Exposure compensation |
1/3EV Step ±5EV |
| AE lock |
Set the Fn button in custom menu to AF/AE lock |
| AE bracket |
3,5,7 frame, in 1/3, 2/3 or 1 EV Step, ±3 EV |
White Balance
|
| White balance |
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature setting (Touch operation is possible) |
| White balance adjustment |
Blue/amber bias, Magenta/green bias |
| Color temperature setting |
2500-10000K in 100K |
| White balance bracket |
3 exposures in blue/amber axis or in magenta/green axis |
Shutter
|
| Type |
Focal-plane shutter |
| Shutter speed |
Still Images: 1/4000 ~ 60 and Bulb (up to approx. 120 seconds)
Motion image: 1/16000 ~ 1/30 (NTSC), 1/16000 ~ 1/25 (PAL) |
| Self timer |
10sec, 3 images/10sec, 2sec |
| Remote Control |
Remote control with bulb function by DMW-RSL1 (Optional) |
Scene Mode
|
| Still Image SCN mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / /Night Portrait / Night Scenery / Illiminatioms / Baby 1, 2 / Pet / Party / Sunset |
| Movie SCN mode |
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food / Objects / Low-light / Party / Sunset
(Activated by selecting Still Image SCN mode then pressing Movie Button. Still Image SCN modes without corresponding Movie SCN mode is recorded in mode suitable for the recording situation.) |
Burst Shooting
|
| Burst speed |
SH: 20 frames/sec(4M), H: 4 frames/sec, M: 3 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Number of recordable images |
7 images (when there are RAW files with the particular speed)
Unlimited consecutive shooting (when there are no RAW files) (depending on memory card size, battery power, picture size and compression) |
Built-In Flash
|
| Type |
TTL Built-in-Flash, GN10.5 equivalent (ISO 160 Em), Built-in Pop-up |
| Flash mode |
Auto, Auto/Red-eye Reduction, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off |
| Synchronization speed |
Less than 1/160 second |
| Flash synchronization |
1st. Curtain Sync, 2nd Curtain Sync. |
| Hot shoe |
TTL Auto with FL220/FL360/FL500(Optional) |
Viewfinder
|
| Type |
Live View Finder (1,440,000 dots equivalent) |
| Field of view |
Approx. 100% |
| Magnification |
Approx. 1.4x / 0.7x (35mm camera equivalent) with 50mm lens at infinity; -1.0 m-1 |
| Eye point |
Approx.17.5mm from eyepiece lens |
| Diopter adjustment |
'-4.0~+4.0(dpt) |
LCD Monitor
|
| Type |
TFT LCD with Touch panel |
| Monitor size |
3.0inch / 3:2 Aspect / Wide-viewing angle |
| Pixels |
460K dots |
| Field of view |
Approx. 100% |
| Monitor adjustment |
Brightness (7 levels), Contrast and Saturation (7 levels), Red tint (7 levels), Blue tint (7 levels) |
Live View
|
| Digital zoom |
2x, 4x |
| Extra Tele Conversion |
Still image: Max.2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.)
Motion image: Max.4.8x (Magnification ratio depends on the recording quality and aspect ratio.) |
| Other functions |
Guide Lines (3 patterns)
Real-time Histogram |
General
|
| Creative control |
(Still image & Motion image) Expressive / Retro / High key / Sepia / High Dyamic |
| Playback mode |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (16x Max.), Slideshow (duration & effect is selectable), Playback Mode (Normal/Picture/AVCHD/Motion JPEG/3D/Category/Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate, Rotate Display, Favorite, Print Set, Protect, Face Rec Edit |
| Protection |
Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel |
| Erase |
Single / Multi / All / Except Favorite |
| Direct print |
PictBridge compatible(Print size, Layout, Date setting are selectable ) |
| USB |
USB 2.0 High Speed |
| HDMI |
miniHDMI TypeC / VIErA Link
Video: Auto / 1080i / 720p / 480p (576p in PAL system)
Audio: Dolby® Digital Stereo Creator |
| Audio video output |
Monaural Type, NTSC / PAL |
| Microphone |
Stereo, Wind-cut: Off / Low / Standard / High, Mic level adjustable (4 levels) |
| Speaker |
Monaural |
| OSD language |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek |
| Battery |
ID-Security Li-ion Battery Pack (7.2V, 1010mAh) Included and Battery Charger |
| Battery life (CIPA standard) |
Approx. 270 images (When using the LCD / LVF) with H-FS014042 |
| Dimensions (W x H x D) |
115.2 x 83.6 x 46.7mm / 4.54 x 3.29 x 1.84 in (excluding protrusions) |
| Weight |
Approx. 336g(Body only)
Approx. 544g (SD Card, Battery and 14-42mm lens included)
Approx. 761g (SD Card, Battery and 42-200mm lens included) |
| Operating temperature |
0 to 40 (32°F to 104°F) |
| Operating humidity |
10% to 80 |
| Software |
PHOTOfunSTUDIO 6.2 HD Edition
SILKYPIX® Developer Studio 3.1 SE
Super LoiloScope (trial version)
USB Driver |
| Standard accessories |
Battery Charger, Battery Pack, Body Cap,
AV Cable, USB Connection Cable, Shoulder Strap, Stylus pen, CD-ROM |
| |
| *1 Use a card with SD Speed Class with "Class6" or higher |
| *2 Use a card with SD Speed Class with "Class4" or higher |
